UHMWPE Wear Resistant Pipe For Industrial Chemical Fluid Delivering

Product Description:

Ultra-high molecular weight polyethylene (UHMWPE) is a type of engineering thermoplastics that boasts an impressive viscosity-average molecular weight of over 2.0 million. Compared to conventional HDPE material, UHMWPE pipe offers superior performance.

UHMWPE is a new and innovative material that has a unique combination of characteristics that make it ideal for a range of applications. These characteristics include high impact strength, excellent abrasion resistance, low coefficient of friction, and exceptional chemical resistance.

UHMWPE pipe is particularly well-suited for use in applications where extreme wear and tear is expected, as it can withstand the harsh conditions and continue to perform reliably. These qualities make UHMWPE pipe an excellent choice for use in diverse industries such as mining, oil and gas, and water treatment.

Overall, the superior performance and unique properties of UHMWPE make it an exciting innovation in the world of engineering thermoplastics and a promising material for future uses and applications.

Features:

UHMWPE Pipe has a wear resistance that is 4 to 7 times greater than Q235 Steel or 10 times that of HDPE (PE100) pipes. This means that it will provide far superior life under most operating conditions.

UHMWPE Pipe has properties that make it superior to any other pipeline on the market today. Its very smooth surface and self-lubricating properties make it highly anti-scaling. This non-stick factor also makes it strong in the marine industry, preventing barnacle formation.

The collaboration of wear resistance and weight reduction (0.93 SG) means that the time between pipe replacements and/or rotations can be increased. It also reduces installation management constraints of lifting gear and excavation requirements, allowing for lower maintenance costs, less time spent on maintenance, less downtime, and less loss of production.

UHMWPE Pipes offer significant cost savings through increased pumping efficiency. With a surface roughness of 0.00022mm, UHMWPE Pipe is extremely smooth and has resultant properties superior to PTFE (Teflon). This means less friction, less pressure loss, and greatly reduced energy inputs to deliver the same result. UHMWPE has a friction coefficient of 0.05, compared to 0.28 for HDPE or 0.58 for Steel (ISO 8295).

UHMWPE Pipe offers chemical resistance second only to PTFE (Teflon). It will provide superior life to other pipeline products in acidic or corrosive applications under 85 degrees C.

The strength of UHMWPE pipes can offer many savings in installation costs. High compressive strength means that it reduces the size or eliminates excavations (greater than 1.5x that of HDPE). The combination of strength and flexibility (>250% tensile elongation) means that concrete bases are not required on wetlands and difficult terrain. High strength and flexibility provide greater protection against damage due to ground subsidence, earthquakes, or other unexpected movement and loading of the pipeline. UHMWPE pipes can be laid directly on the seabed, further reducing installation costs.

Technical Parameters:

Applications:

One of the most common applications of Jiubei's UHMWPE pipes is for slurry transportation. The pipes are able to withstand the abrasive nature of slurry, making them ideal for use in mining and dredging operations. Additionally, the pipes are lightweight, which reduces transportation costs and makes installation easier.

The UHMWPE pipes are also suitable for use in chemical processing plants. They are resistant to a wide range of chemicals, making them ideal for transporting corrosive liquids and gases. The pipes are available in a range of colors, including black, white, blue, green, and yellow, making it easy to identify the contents of the pipe.

The UHMWPE pipes are available in a range of sizes, from DN100 to DN1200, and are connected using steel flanges, threads, sockets, or other methods. The pipes have a thickness of 3-50mm, which makes them highly durable and resistant to damage from impact or abrasion.

Jiubei's UHMWPE pipes are certified to ISO and SGS standards and have a minimum order quantity of 100m. The price of the pipes is between 5-8 USD/m, and they are supplied in standard sea-worthy packaging. Delivery time is 14 days, and payment terms are TT/LC. The supply ability is 3000m/month, ensuring that customers can always get the pipes they need when they need them.

Support and Services:

The UHMWPE pipe product is supported by a team of technical experts who are available to provide product support and services. Our technical support team can assist with product selection, installation guidance, and troubleshooting. We also offer a range of services including custom design and engineering, field support, and training. Our goal is to ensure that our customers have the information and resources they need to maximize the performance and longevity of their UHMWPE pipe products.
