Product Details:
|
| Connection: | Steel Flanges | Thickness: | 3-50mm |
|---|---|---|---|
| Pressure: | 0.25-2.5MPa | Connection: | Flange,Thread,Socket,etc. |
| Package: | Wooden Case,Pallet,etc. | Production Method: | Extruding |
| Diameter: | 1/2''-48'' | Application: | Mining, Oil&Gas, Sand/ Slurry Dredging Etc. |
| Highlight: | Dredging UHMWPE Slurry Pipe,Ultra Tough UHMWPE Slurry Pipe,Flange Connected UHMWPE Slurry Pipe |
||
Ultra-high molecular weight polyethylene or UHMWPE is an innovative type of engineering thermoplastic that possesses a viscosity-average molecular weight of more than 2.0 million. This exceptional molecular weight provides UHMWPE with distinct characteristics and properties unlike other plastics commonly utilized in engineering.
One of the most advantageous applications of UHMWPE material is in the form of pipes. Ultra-high molecular weight polyethylene pipes have been found to exhibit superior performance when compared to conventional HDPE material. This is due to UHMWPE's exceptional impact strength, abrasion resistance, and low coefficient of friction.
UHMWPE Pipe has a wear resistance 4 to 7 greater than Q235 Steel or 10 times that of HDPE (PE100) pipes under the same operating conditions. This means that UHMWPE Pipe will give you far superior life under most operating conditions.
UHMWPE Pipe has a very smooth surface and self-lubricating properties, making it far superior in anti-scaling properties than any other pipeline on the market today. Its non-stick factor also leads to its strength in the marine industry, preventing barnacle formation.
The collaboration of wear resistance and weight reduction (0.93 SG) means that the time between pipe replacements and/or rotations can be increased, while also reducing installation management constraints of lifting gear and excavation requirements. This greatly reduces maintenance time and costs, as well as downtime and loss of production.
In addition to the benefits mentioned above, UHMWPE Pipes offer significant cost savings through increased pumping efficiency. The extremely smooth surface with a roughness of 0.00022mm has resultant properties superior to PTFE (Teflon), resulting in less friction, less pressure loss, and greatly reduced energy inputs to deliver the same result.
UHMWPE Pipe has chemical resistance that is second only to PTFE (Teflon). It will offer superior life compared to other pipeline products in acidic or corrosive applications under 85 degrees C.
UHMWPE Pipe's strength offers many savings in installation costs. High compressive strength means a reduced size or even completely eliminating excavations (greater than 1.5x that of HDPE). The combination of strength and flexibility (>250% tensile elongation) means that concrete bases are not required on wetlands and difficult terrain. The high strength and flexibility also provide greater protection against damage due to ground subsidence, earthquakes, or other unexpected movement and loading of the pipeline. UHMWPE Pipe can be laid directly on the seabed.
| Technical Parameter | Description |
|---|---|
| Color | Black, White, Blue, Green, Yellow, Etc. |
| Application | Mining, Oil&Gas, Sand/ Slurry Dredging Etc. |
| Advantage | High Wear Resistance,High Impact Strength,etc. |
| Material | UHMWPE |
| Accessories | Bolts, Nuts And Washers |
| Thickness | 3-50mm |
| Production Method | Extruding |
| Diameter | 1/2''-48'' |
| Connection | Flange,Thread,Socket,etc. |
| Temperature | -40℃~80℃ |
This table shows the technical parameters for UHMWPE pipe, a wear resistant material commonly used in mining, oil&gas, sand/ slurry dredging, etc. The UHMWPE pipe is available in various colors such as black, white, blue, green, yellow, etc. It comes with accessories such as bolts, nuts and washers, and is produced using the extruding method. The thickness of the pipe ranges from 3-50mm, while the diameter ranges from 1/2''-48''. The connection options include flange, thread, socket, etc. The UHMWPE pipe is suitable for use in temperatures ranging from -40℃ to 80℃.
UHMWPE slurry pipe, UHMWPE sand dredging pipe, and wear resistant UHMWPE pipe are some of the common applications of this material.
One of the key benefits of UHMWPE pipes is their ease of installation. Unlike traditional metal pipes, which can be difficult and time-consuming to install, UHMWPE pipes can be easily cut and joined using standard tools and fittings. This makes them an ideal choice for applications where time and labor costs are a concern.
The Jiubei UHMWPE slurry pipe is specifically designed for use in mining and mineral processing applications. Its high abrasion resistance and low friction coefficient make it ideal for transporting abrasive materials like coal, iron ore, and copper concentrate.
The UHMWPE sand dredging pipe is another popular product in the Jiubei line. Designed for use in sand and gravel dredging operations, this pipe is able to withstand the high pressures and abrasive materials associated with these applications. Its smooth inner surface also helps to reduce friction and minimize clogging.
Whether you're looking for a reliable solution for mining, oil and gas, or sand/slurry dredging, Jiubei UHMWPE pipes are an excellent choice. With ISO and SGS certification, a minimum order quantity of 100m, and a supply ability of 3000m/month, you can be confident in the quality and availability of these pipes. And with a price range of 5-8 USD/m and a delivery time of 14 days, they offer exceptional value for any application.
Each Jiubei UHMWPE pipe comes with all the necessary accessories, including bolts, nuts, and washers, and is available in a range of lengths from 1-12m. With a pressure rating of 0.25-2.5MPa, these pipes are suitable for a wide range of applications, and their standard sea worthy packaging ensures safe and secure transport to any location.
The UHMWPE Pipe product technical support and services include:
Our technical support team is available to assist with any questions or concerns regarding the use and maintenance of our UHMWPE Pipe product.
