Product Details:
|
Temperature: | -40℃~80℃ | Package: | Wooden Case,Pallet,etc. |
---|---|---|---|
Certificate: | ISO9001,CE,etc. | Connection: | Flange,Thread,Socket,etc. |
Diameter: | 1/2''-48'' | Material: | UHMWPE |
Thickness: | 3-50mm | Color: | Black, White, Blue, Green, Yellow, Etc. |
Highlight: | Oil and Gas UHMWPE Pipes,UHMWPE Pipes for Oil and Gas,Corrosion Resistant UHMWPE Pipes |
Ultra-high molecular weight polyethylene (UHMWPE) is a cutting-edge engineering thermoplastic that possesses a viscosity-average molecular weight surpassing 2.0 million. In the industry, this material is considered to be a game-changer, due to its outstanding properties and numerous benefits.
In comparison to conventional HDPE (high-density polyethylene), Ultra-high molecular weight polyethylene pipe demonstrates superior performance in various applications. The remarkable characteristics of UHMWPE include its high impact strength, superior abrasion resistance, and excellent chemical compatibility with a wide range of substances. Moreover, the material boasts self-lubricating and low frictional properties that make it ideal for use in numerous industrial applications for creating bearings, bushings, and other products.
Besides these features, Ultra-high molecular weight polyethylene pipe also offers exceptional resistance to UV radiation, thermal expansion, and moisture absorption. The easy fabrication and installation properties make it a popular choice; used widely in the construction industry for conveying potable water, chemicals, gases, and slurries.
To sum up, Ultra-high molecular weight polyethylene (UHMWPE) has the potential to revolutionize the engineering thermoplastics industry due to its impressive molecular weight, numerous advantageous properties, and applications in various industries.
UHMWPE Pipe offers a longer lifespan than Q235 Steel or HDPE (PE100) pipes. In fact, its wear resistance is 4 to 7 times greater than Q235 Steel or 10 times greater than HDPE pipes under the same operating conditions. This makes UHMWPE Pipe a superior choice for durability and longevity in most operating conditions.
One of the reasons for UHMWPE Pipe's superior lifespan is its anti-scaling properties. Its smooth surface and self-lubricating properties make it far less likely to develop scaling than any other pipeline on the market today. This quality is especially beneficial in the marine industry, where barnacle formation can weaken pipelines.
Choosing UHMWPE Pipe can also lead to lower maintenance costs, less maintenance time, less downtime, and less loss of production. With its superior wear resistance and weight reduction, the time between pipe replacements or rotations can be increased. This reduces the need for installation management of lifting gear and excavation requirements.
Additionally, UHMWPE Pipe offers savings through increased pumping efficiency. Its surface roughness of 0.00022mm is extremely smooth, with a friction coefficient of 0.05 compared to 0.28 for HDPE and 0.58 for Steel. This means less friction, less pressure loss, and greatly reduced energy inputs to deliver the same result.
UHMWPE Pipe is also highly resistant to chemicals and corrosion, second only to PTFE (Teflon). It is an ideal choice for acidic or corrosive applications under 85 degrees C.
The strength of UHMWPE pipes can offer many savings in installation costs. Its high compressive strength means reduced size or eliminating excavations, greater than 1.5x that of HDPE. Its combination of strength and flexibility (>250% tensile elongation) means concrete bases are not required on wetlands and difficult terrain. High strength and flexibility also provide greater protection against damage due to ground subsidence, earthquakes, or other unexpected movement and loading of the pipeline. Finally, UHMWPE Pipe can be laid directly on the seabed.
Technical Parameter | Description |
---|---|
Product Name | UHMWPE dredging pipe |
Pressure | 0.25-2.5MPa |
Connection | Steel Flanges |
Certificate | ISO9001, CE, etc. |
Material | UHMWPE |
Advantage | High Wear Resistance, High Impact Strength, etc. |
Connection | Flange, Thread, Socket, etc. |
Temperature | -40℃~80℃ |
Accessories | Bolts, Nuts And Washers |
Production Method | Extruding |
Color | Black, White, Blue, Green, Yellow, Etc. |
Jiubei UHMWPE pipe is perfect for a wide range of applications in various industries. Its high wear resistance and impact strength make it ideal for carrying abrasive slurries and materials. It is commonly used in industries such as mining, dredging, and chemical processing.
The UHMWPE slurry pipe is specifically designed to handle abrasive slurries. The smooth surface of the pipe ensures that the slurry flows smoothly without any blockages or interruptions. This ensures that the pipeline operates efficiently and effectively, reducing downtime and maintenance costs.
The wear-resistant UHMWPE pipe is perfect for handling abrasive materials such as sand, gravel, and rocks. It is commonly used in sand dredging applications, where the pipe is used to transport sand from one location to another. The smooth surface of the pipe ensures that the sand flows smoothly without any blockages or interruptions.
The Jiubei UHMWPE pipe comes in a range of models from Dn100~1200, with a thickness of 3-50mm. It is certified with ISO and SGS, and can be ordered with a minimum quantity of 100m. The price is competitive, ranging from 5-8 USD/m and can be delivered within 14 days.
The UHMWPE pipe's surface can be smooth or sandblasted, depending on the application. It comes with accessories such as bolts, nuts, and washers, making installation easy and hassle-free.
The UHMWPE pipe is highly durable and has a long service life, reducing the need for frequent replacements. It can handle pressures of up to 2.5MPa, making it suitable for a range of applications.
In summary, Jiubei UHMWPE pipe is an excellent choice for industries that require a durable, wear-resistant, and efficient pipeline for transporting abrasive slurries and materials.
Order now and experience the benefits of using Jiubei UHMWPE pipe.
Our UHMWPE pipe product technical support and services include:
- Comprehensive technical information about the product
- Installation and operation advice
- Troubleshooting assistance
- Maintenance and repair guidance
- Warranty and product performance information
- Customization and specialty solutions
