Product Details:
|
Color: | White With Blue Strips | Tensile Strength: | High |
---|---|---|---|
Corrosion Resistance: | Excellent | Temperature: | -60~80degree |
Impact Resistance: | Excellent | Density: | 0.945 |
Pressure: | 0.4~2.0Mpa | Length: | 5.8/11.8m Per Length |
Highlight: | Customized Diameter Dredging HDPE Pipe,5.8m Dredging Pipe,Excellent Impact Resistance Dredging HDPE Pipe |
Therm PE100 pipe is produced with a highly reflective white exterior coating, which is extruded simultaneously with the main pipe. This innovative co-extrusion technology ensures that over 95% of the pipe is made from standard black PE material, while a thin white coating is applied to the outside to reflect sunlight and reduce heat absorption. Despite being a tried and tested technology, co-extruded pipe has traditionally been more expensive than standard black poly pipe. However, Acu-Tech has invested in state-of-the-art extrusion machinery, allowing us to produce co-extruded PE pipe more efficiently. This means that the cost of our co-ex HDPE pipe is only slightly higher than standard black HDPE pipe. Furthermore, our new machinery also has the capability to produce white coex pipe with coloured stripes, making it easier to identify the contents of the pipeline. For example, blue stripes denote white water pipe, red stripes indicate white rural pipe, and lilac stripes signify white recycled water pipe. For custom needs, we can also produce white pipe with stripes in any other colour.
One of the main benefits of Acu-Therm HDPE pipe for above ground applications is its full white coating, which significantly reduces solar heating of both the pipe and its contents. Our tests have shown that this coating can reduce solar heating by more than 50%. In addition, our HDPE pipe offers excellent UV resistance, ensuring its durability even in sunny or hot environments.
Due to its white coating and lower operating temperatures, Acu-Therm HDPE pipe can be used with lower pressure ratings, resulting in cost savings in material and increased flow rates. The reduced thermal expansion and flexibility of our pipe also means that there is less need to install the pipeline in a zig-zag manner to accommodate topographical features.
In addition to its above ground applications, Acu-Therm HDPE pipe is an ideal solution for temporary water supply. Our twin-wall pipe, also known as co-ex or coex pipe, is manufactured by extruding white material at the same time as black material, creating a strong bond between the two layers. This ensures that our pipes are reliable and durable, as they are produced according to the ISO4427 standard for PE pipes used in pressure applications.
Our Acu-Therm HDPE pipe can be joined using electrofusion fittings, butt welding equipment, or compression fittings. We offer a range of sizes in SDR7.4, SDR9, SDR11, SDR13.6, SDR17, SDR21, SDR26, SDR33, and SDR41, ensuring that we can meet the needs of any project.
Technical Parameters | Value |
---|---|
Length | 5.8/11.8m per length |
Corrosion Resistance | Excellent |
Temperature | -60~80℃ |
Color | White with blue strips |
Tensile Strength | High |
Diameter | Customized |
Application | Dredging, Water Supplying |
Connection | Welding, Steel Flanges |
Pressure | 0.4~2.0Mpa |
Density | 0.945 |
Jiubei DN400 HDPE Pipe is a high-quality, durable product designed for dredging and water supply applications. Made in China, it has been certified with ISO and SGS, ensuring its reliability and safety. With a minimum order quantity of 200m, this product is suitable for both large and small scale projects.
Our DN400 HDPE Pipe is available at a competitive price of 12-28 USD/m, making it a cost-effective choice for your dredging and water supply needs. It is also packaged in standard sea worthy packaging, ensuring its protection during transportation.
Our DN400 HDPE Pipe is specifically designed for use in dredging and water supply projects. Its strong and flexible nature makes it ideal for handling slurry and other abrasive materials, making it perfect for dredging applications. It can also be used for water supply, providing a reliable and leak-free solution.
The DN400 HDPE Pipe can be connected through welding or steel flanges, providing a secure and durable connection. Its diameter can be customized according to your project's requirements, ensuring a perfect fit for your needs.
Our DN400 HDPE Pipe is produced using a white-black co-extrusion method, ensuring its strength and durability. This production method also allows for customization in terms of color, making it suitable for different project requirements.
Each length of our DN400 HDPE Pipe measures 5.8 or 11.8 meters, providing a convenient and efficient solution for your dredging and water supply needs. Its long length also reduces the need for frequent joints, ensuring a continuous and uninterrupted flow.
Jiubei DN400 HDPE Pipe is a top-quality product that is perfect for dredging and water supply applications. With its strong and flexible nature, customizable diameter, and convenient length, it is a reliable and efficient solution for your project needs. Contact us now to place your order and experience the benefits of our superior product.
Our Dredging HDPE Pipe is a highly customizable product designed and manufactured by Jiubei. It is made using the latest technology and conforms to international standards, ensuring high-quality and reliable performance. The following are the specifications and features of our product:
Our Dredging HDPE Pipe is also known as a Slurry pipe due to its high strength and durability, making it ideal for transporting slurries in various industries. This HDPE pipe is a PN10 ISO4427 rated pipe which guarantees its high performance and ability to withstand high pressures. It is perfect for use in dredging operations and other applications that require reliable, leak-proof and corrosion-resistant piping solutions.
The Dredging HDPE Pipe will be carefully packaged and shipped to ensure its safe arrival at its destination. The packaging and shipping process will follow industry standards and regulations to ensure the product's quality and integrity.
The Dredging HDPE Pipe will be packaged in high-quality, durable materials to protect it during transportation. The pipe will be wrapped in plastic and placed in a sturdy wooden crate. The crate will be securely sealed to prevent any damage or tampering during shipping.
Each pipe will be labeled with important product information, such as size, length, and manufacturer, for easy identification and handling.
The Dredging HDPE Pipe will be shipped via a reputable and reliable carrier to ensure timely and safe delivery. The shipping method will depend on the size and quantity of the pipes ordered, as well as the destination.
The pipes will be carefully loaded onto the shipping container to prevent any shifting or damage during transportation. Once loaded, the container will be sealed and securely fastened to the shipping vessel.
Customers will be provided with a tracking number to monitor the status of their shipment and ensure a smooth delivery process.
Upon arrival at the destination, the pipes will be unloaded and inspected to ensure they have arrived in excellent condition. Any issues will be addressed promptly to ensure customer satisfaction.
By following strict packaging and shipping procedures, we guarantee that the Dredging HDPE Pipe will reach our customers in perfect condition, ready for use in their projects.
