Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats

Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats
Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats

Large Image :  Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats

Product Details:
Place of Origin: China
Brand Name: JiuBei
Certification: ISO
Model Number: DN200 PE pipe float
Payment & Shipping Terms:
Minimum Order Quantity: 10 pairs
Price: USD50~500/pair
Packaging Details: STANDARD SEA WORTHY PACKAGE
Delivery Time: 10days
Supply Ability: 300pairs/month

Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats

Description
Name: Factory Direct Price Orange Dredging Pipe Float Plastic Pontoon Floater For Dredging Material: Out Shell PE, Inner Foam: PU
Color: Orange /Yellow Dimension: DN60-1200mm
Connection: Galvanised Bolts Nuts And Washers Shape: Clinder
High Light:

floating rubber buoy

,

floating buoy for water

,

float buoyancy

Large Capacity Long Lifespan HDPE Pontoon Floats for Rubber Hose



Polyethylene Foam Floats always

They consist of two half-shells, the inner and outer diameter and total buoyancy of which are adapted to the demand. The floats are assembled with a hinge and stainless steel screws or zinc plated steel screws.The floats are filled with closed cell, variable density EPS foam at the base of the hydrostatic pressure that the floats must withstand.The two halves are joined together on the tube by four steel bolts, two on each side, to ensure optimal clamping with the tube.

CASE: Dredging

Excavator pipe is used to transfer the material to the desired area.

The pipe is usually connected by flange, and flange parts are connected by bolt, which is very easy to operate.The key factors for the correct floater model selection including the arrangement and arrangement of the floater, the materials to be transported, the length of the pipeline, etc.

Advantages:

High environmental protection: Made of environmentally friendly food grade HDPE material.

Impact resistance: The outer housing is made of rotationally molded plastic material and the inner polyurethane foams and is impact resistant.

Virtue:

Light weight: when the typhoon is encountered, the buoy will not be distorted.

Corrosion resistance: The buoy shell is uniquely formed by PE material, which is resistant to acid, alkali and seawater corrosion.


PE Float Dimension:

Float I.D.
(mm)
Float O.D.(mm) Float
Length(mm)
Thickness
of Hull(mm)
Floater
Buoyancy (kg)
110 500 500 7 98
125 500 800 7 150
160 500 800 7 145
220 600 700 7 180
250 600 700 7 175
280 700 900 7 340
310 900 1000 8 550
320 1000 1000 9 650
350 950 1000 9 600
390 1000 1000 9 600
400 1100 1100 9 900
450 1200 1200 11 1100
460 1300 1300 12 1400
495 1300 1300 12 1400
520 1300 1450 12 1500
550 1300 1500 12 1750
560 1400 1500 12 1900
600 1400 1600 13 2100
620 1450 1700 13 2400
670 1500 1860 14 2800
720 1500 1860 14 2800
735 1500 1800 14 2700
760 1800 2050 15 3100
800 1800 2160 15 3300
890 2000 2400 15 4600
940 2040 2500 16 4900
1040 2400 2600 16 7000
1140 2300 2550 16 7000
(Support customization)





Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats 0Rubber Hose Water Pipe Floats Buoys Dock Large Capacity HDPE Pontoon Floats 1
