Product Details:
|
BOOM Material: | Rubber AND Foam Filled | Skirt Material: | PVC |
---|---|---|---|
Boom Diameter: | 600`1500mm | Unit Length: | 20m/length |
Highlight: | floating litter boom,floating turbidity barrier,turbidity control barrier |
PVC Oil Containment Boom Floating Curtains and Silt Curtains for Port
Turbidity curtain, silt barrier, silt screen, or turbidity barriers, as they are sometimes called, are floating oil spill containment boom used in marine construction, dredging, and remediation?projects?to control the silt and sediment in a body of water.
Marine turbidity screen for dredging are custom designed and manufactured specifically to project requirements. Complete information of specific hydraulic conditions at marine construction sites is important to ensure the marine containment booms system is properly designed and effective when deployed in those hydraulic conditions.
Technical Parameters:
Technical Date | |||||||
Model | WGJ600 | WGJ800 | WGJ900 | WGJ1000 | WGJ1100 | WGJ1500 | |
Freeboard(mm) | 210 | ||||||
Draught(mm) | 280 | ||||||
Section’s length(m) | 20 | ||||||
Working condition | Tention strength(kn) | 60 | 65 | 80 | 90 | 100 | 130 |
Wave height(m) | 0.6 | 0.75 | 1.0 | 1.5 | 1.5 | 2.0 | |
Wind speed(m/s) | 10 | 15 | 15 | 15 | 20 | 20 | |
Current speed(knot) | 1.2 | 1.5 | 2.0 | 3.0 | 3.0 | 3.0 |
Note: We pursue perfect products quality, if any change, subject to confirmation from both parties.
