Product Details:
|
BOOM Material: | Rubber AND Foam Filled | Skirt Material: | PVC |
---|---|---|---|
Boom Diameter: | 600`1500mm | Unit Length: | 20m/length |
Highlight: | floating silt curtain,floating silt screen,floating booms for debris |
Floating Turbidity Curtains and Silt Curtains
Fabricated with special rubber cloth to form the main body, thus high intensity, long endurance, oil-resistance, erosion-resistance are ensured.
Covered with fire- proof rubber cap which can meet the requirement of fir-resistance.
Special designed solid floats with higher buoyancy, boom body uniformly exerted by forces, with higher overall strength and good vertical stability.
Universal quick connectors for swift and reliable connection of domestic and foreign oil boom sections facilitate international or regional combined operations.
Chain-wrapped tensioned counterweight reinforces intensity of oil barrier. Oil containment boom skirt can form a concave facilitating to retain oil, and there is good oil retaining status in high-speed water flow, namely”concave effect”
Make choice among zipper counterweight, cast iron counterweight and built-in counterweight according to demands.
Noctilucent or colored outer rubber cover would be decorated according to customer’s requirements.
Technical Parameters:
Technical Date | |||||||
Model | WGJ600 | WGJ800 | WGJ900 | WGJ1000 | WGJ1100 | WGJ1500 | |
Freeboard(mm) | 210 | ||||||
Draught(mm) | 280 | ||||||
Section’s length(m) | 20 | ||||||
Working condition | Tention strength(kn) | 60 | 65 | 80 | 90 | 100 | 130 |
Wave height(m) | 0.6 | 0.75 | 1.0 | 1.5 | 1.5 | 2.0 | |
Wind speed(m/s) | 10 | 15 | 15 | 15 | 20 | 20 | |
Current speed(knot) | 1.2 | 1.5 | 2.0 | 3.0 | 3.0 | 3.0 |
Note: We pursue perfect products quality, if any change, subject to confirmation from both parties.
