PRODUCTS DETAILS

Home > Products >

Slurry Wear Resistant Pipe Lined By Ceramic Bend Anti Wear Mild Steel Pipe

Products

Slurry Wear Resistant Pipe Lined By Ceramic Bend Anti Wear Mild Steel Pipe

MOQ:	3m
Price:	usd50-500/m
Standard Packaging:	Standard sea worthy packaging
Delivery Period:	7working days
Supply Capacity:	3000m/month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

JiuBei

Certification

ISO

Name:

Super Wear Resistant Pipe

Material:

Outlayer:Carbon Stee Inner:chromium Carbide

Color:

As Request

Dimension:

DN90~2000mm

Installation:

Welding

Warranty:

12months

Highlight:

Wear Resistant Pipe lined

Wear Resistance Slurry Pipes

Wear resistant ceramic lined pipe bend

Product Description

Anti-Wear Mild Steel Pipe

Product Details
ceramic coated elbow pipe, also called metal-ceramic coated composite pipe, is a new type of wear-resistant pipe, which uses a special process to firmly connect ceramic and metal pipes, and uses the high strength and high hardness of wear-resistant ceramics to increase wear resistance and pipe life.

The outer layer of the ceramic-coated bow is made of steel, and the inner layer is made of a special wear-resistant and high-temperature resistant ceramic that does not crack when heated. During construction, flanges, vents, explosion-proof doors, etc. can be welded, and direct welding methods can also be used. It is better than stone wear-resistant cast iron pipe, wear-resistant steel pipe, wear-resistant rare earth steel pipe, bimetal composite pipe, plastic steel pipe and
steel pipe rubber, which are not easy to weld or can not be welded. during construction.The ceramic-coated sheet has good resistance to mechanical impact, and the composite layer will not crack or fall off during transportation, installation and impact.

Advantages
wear-resistant ceramic manifold pipe inner layer is a new type of ceramic such as alumina ceramic, which has high hardness, high temperature resistance and excellent corrosion resistance. jump.

Compared with traditional wear-resistant tubes, wear-resistant ceramic tubes also have significant advantages such as light weight and convenient installation.

Technical Data

Al2O3	SiO2	CaO	MgO	Na2O
92~93%	3~6%	1~1.6%	0.2~0.8%	0.1%

Physical properties:

Specific gravity (g/cc)	>3.60
Apparent porosity (%)	0
Flexural Strength (20 degree centigrade, Mpa)	334
Compressive strength (20degree centigrade, Mpa)	1770
Rockwell hardness (kg/mm 2 )	918
Vickers hardness (hv)	>750
Moh's hardness (scale)	≥9
Thermal Expansion (20-800degree centigrade, x10-6/degree centigrade)	8.30
Crystal Size (μm)	1.3~3.0

Detail images:

Slurry Wear Resistant Pipe Lined By Ceramic Bend Anti Wear Mild Steel Pipe

Tags:

Products

MOQ:	3m
Price:	usd50-500/m
Standard Packaging:	Standard sea worthy packaging
Delivery Period:	7working days
Supply Capacity:	3000m/month

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

JiuBei

Certification

ISO

Name:

Super Wear Resistant Pipe

Material:

Outlayer:Carbon Stee Inner:chromium Carbide

Color:

As Request

Dimension:

DN90~2000mm

Installation:

Welding

Warranty:

12months

Minimum Order Quantity:

Price:

usd50-500/m

Packaging Details:

Standard sea worthy packaging

Delivery Time:

7working days

Supply Ability:

3000m/month

Highlight

Wear Resistant Pipe lined

Wear Resistance Slurry Pipes

Wear resistant ceramic lined pipe bend

Product Description

Anti-Wear Mild Steel Pipe

Technical Data

Al2O3	SiO2	CaO	MgO	Na2O
92~93%	3~6%	1~1.6%	0.2~0.8%	0.1%

Physical properties:

Specific gravity (g/cc)	>3.60
Apparent porosity (%)	0
Flexural Strength (20 degree centigrade, Mpa)	334
Compressive strength (20degree centigrade, Mpa)	1770
Rockwell hardness (kg/mm 2 )	918
Vickers hardness (hv)	>750
Moh's hardness (scale)	≥9
Thermal Expansion (20-800degree centigrade, x10-6/degree centigrade)	8.30
Crystal Size (μm)	1.3~3.0

Detail images:

Slurry Wear Resistant Pipe Lined By Ceramic Bend Anti Wear Mild Steel Pipe
