Industrial Grade Multipurpose Composite Flexible Hose High Pressure Chemical Resistant

Products

Industrial Grade Multipurpose Composite Flexible Hose High Pressure Chemical Resistant

MOQ:	1
Price:	10
Standard Packaging:	Wood pallet
Delivery Period:	5-8days
Payment Method:	T/T
Supply Capacity:	3000m

Detail Information

Product Description

Detail Information

Place of Origin

China

Brand Name

Jiubei

Model Number

1-10inch

Color:

Customized

Material:

Composite Material

Length:

Customized

Connection:

Flanges, Camlock And So On

Highlight:

Industrial Grade Multipurpose Hose

High Pressure Multipurpose Hose

Chemical Resistant Multipurpose Hose

Product Description

Industrial Grade Multipurpose Composite Flexible Hose High Pressure Chemical Resistant

Composite hose by a variety ot materials multi-layer sealing construction, in the mostsevere environmenstill has a good resistance to rupture and leakage resistance, will not suddenly burst. it can easily handlethe transfer of gasoline, diesel, crude oil and many other chemical liquids. High flexibility even in coldweather.Light weight, toughness, easy handling, soft body, flexible use, high temperature, low temperature.anti-aging, non-deformation, corrosion resistance, bare inner spiral metal wire and specialinner layer,with reliable static electricity dissipation performance,Hongtai composite hoses have been used to replace traditional rubber hoses and metal hoses in docks.tankers, petrochemical warehouses, tanker trucks, chemical plants and other fields because oftheir manyadvantages such as chemical resistance, safety, flexibility,lightness, easy handling and durability.

HOSE SIMPLE CLASSIFICATION

The composite hoses are available in sizes from 1 to 10" and working pressures from 100psi to 360psiThe use of a variety of different polymer sealing barrier materials, can be in the extreme harsh conditionsof the transport ofhighly hazardous materials.

MULTI-PURPOSE OILRESISTANT HOSE
PAINT AND COATINGHOSE
HOSE FOR TANKTRUCKS
LOADING AND UNLOADINGHOSES FOR DOCK SHIPS
MULTI PURPOSE CHEMICALCONVEYING PIPE
LOW TEMPERATURERESISTANT HOSE
HIGH TEMPERATURERESISTANT HOSE
OILFIELD FRACTURING HOSE
OIL AND GASRECOVERY HOSE

Technical Parameters

I.D (MM/IN)	Max. WP. (psi/Mpa)	Blasting Pressure (psi/Mpa)	Reference Weight (kg/m)	Bending Radius (mm)
25/1	150/1.03	600/4.2	0.9	100
38/1.5	150/1.03	600/4.2	1.5	110
51/2	150/1.03	600/4.2	1.8	125
65/2.5	150/1.03	600/4.2	2.5	150
76/3	150/1.03	600/4.2	2.3	200
100/4	150/1.03	600/4.2	9.9	500
150/6	150/1.03	880/6.06	1.2	100
25/1	220/1.516	880/6.06	2.0	120
38/1.5	220/1.516	880/6.06	2.2	180
51/2	220/1.516	880/6.06	2.5	260
65/2.5	220/1.516	880/6.06	3.0	260
76/3	220/1.516	880/6.06	5.0	400
100/4	220/1.516	880/6.06	14	600
152/6	220/1.516	880/6.06	22	800
202/8	220/1.516	880/6.06	27	1100
252/10	220/1.516	880/6.06
